One touch Window Module Suits Mazda BT-50 (ford Ranger platform) Passengers Window Switches

Name: One touch Window Module Suits Mazda BT-50 (ford Ranger platform) Passengers Window Switches
SKU: WM5.
Availability: OutOfStock

Code: WM5.

One touch Window Module Suits Mazda BT-50 (ford Ranger platform) Passengers Window Switches - Image 2

Once installed to any of the passenger’s window switches, to operate simply tap the existing switch once and the window will fully open or close without the need to keep holding the window switch in position.

Manual operation is still maintained, hold the switch to operate the window and release at any time for the window to stop.

Once fitted to the passenger’s window switch the corresponding window switch on the drivers master window switch becomes full auto for that particular window, enabling the driver to have full auto function at their fingertips in addition to the passenger.

AUD$48.00

Out of stock

Description

Suits:

First generation Mazda-BT-50 (UN models)

Second generation Mazda BT-50 (UR models)

(using the Ford Ranger platform).

NOT suitable for the BT-50 using the Isuzu D-Max platform (use WM3-A).

Module Function:

Transforms a single passengers window switch and the corresponding window switch on the drivers master window switch to full one touch auto open/close operation.

Can be used in conjunction with our existing auto window systems or as a standalone unit, add one or to all passengers windows for full auto operation.

The patch harness is fully 100% direct plug & play connecting to the factory window switch connector, so no splicing or connecting to any individual wires is required.

IMPORTANT NOTE: Our system uses current sensing to operate the window regulator, it does not use anti pinch so if a object is in encountered between the window and door frame the window will stop. Once the obstruction has been removed the window switch can be reused to continue window movement.

The window lock switch on the master window switch can still be used to isolate the passengers windows from operating.

If your windows are not functioning properly (very slow at opening or closing) our system will not be suitable as it will detect over current due to the window regulator working harder than it should stopping the window movement.

System includes:

Module – Auto window control module
Y patch harness with full 100% direct plug & play connectors (no splicing wires required)
Adhesive pad (hook & loop) to attach module to inside trim

Operating features:

Hold window switch up or down for manual control from the passengers or drivers master window switch

Window switch functions normally – window stops when the switch is released.

Tap the window switch once to initiate full auto window operation from the passengers or corresponding drivers master window switch

Window will automatically close / open without the need to keep holding the window switch.

Compatible with our auto window and auto window and mirror modules

All window functions are maintained when remotely opening or closing the windows from partially open to fully opening or closing.

Additional information

Weight	0.075 kg
Dimensions	1 × 9 × 3 cm

Make	Model	Year
Mazda	BT-50 (UN Models)	2009 - 2012
Mazda	BT-50 (UR Models)	2012 - 2020
